Boiler Tech 1 Book:
- Chapter 1: Steam Boilers
- Chapter 2: Boiler Systems
- Chapter 3: Steam System Fittings
- Chapter 4: Steam System Accessories
- Chapter 5: Feedwater Systems
- Chapter 6: Water Treatment
- Chapter 7: Combustion Equipment
- Chapter 8: Fuels and Combustion
- Chapter 9: Combustion and Boiler Controls
- Chapter 10: Draft Systems
- Chapter 11:Instrumentation and Control Systems
- Chapter 12: Steam Boiler Operation
- Chapter 13: Licensing
Exams 1-6
Boiler Operator 1 uses High Pressure Boilers Fifth Edition written by Frederick M. Steingress, Harlod J. Frost, and Daryl R. Walker. as the written material for the class subjects.
Course Syllabus:
Primary Areas of Focus for Boiler Level One
Boilers – steam cycle, fuel/energy source, utility boilers, industrial boilers, co-generation
1. Boilers – Knowledge in the operation, maintenance, repair, economics of basic systems including the use of steam, the energy source to produce the steam, the distinction between industrial and utility boilers, and a good concept of how steam is generated from a heat source other than combustion within a boiler.
a. Steam Cycle – The Boiler Operator should know the Rankine Cycle, the effects of reheat cycles and regenerative feed water heating.
b. Fuel/Energy Source –The Boiler Operator should know the types of fossil fuels used in a boiler, coal, oil, gas as well as the heat derived from nuclear fuel such as uranium.
c. Utility Boilers – The Boiler Operator should know that utility boilers are those plants that generally supply electricity to most of the United States . These boilers are most often fired with coal but are also fired with fuel oil and gas. Utility boilers have reheat cycles, and require very elaborate water treatment systems.
d. Industrial Boilers –The Boiler Operator should know industrial boilers are most often used for process steam, such as heating, driving operating turbines, for fans or pumps, and other process work.
e. Cogeneration –The Boiler Operator should know that cogeneration is a system in which fuel is used to produce energy and the heat from the fuel is then directed to be used by a boiler to conserve energy and achieve the maximum efficiency from the heat generated.
Boiler Design/Application, heat transfer, steam properties, control devices, furnace design, economic devices, firing equipment, and draft.
2. Boiler Design/Application – The boiler operator should know: how the application affects the design, size, and type of boiler to be used. Also, the types of heat transfer, how they differ, and where each takes place within the furnace. The boiler operator must have an understanding of the relationship between steam pressure and temperature and how to control their parameters. The boiler operator must have knowledge of the rules for construction of boilers, including material properties, accessories supplied, and heat source. Knowledge is needed for plants that span the last fifty year or more.
a. Boiler design/application – The boiler operator should know fire tube, vertical (submerged and nonsubmerged), horizontal, water tube, and cast iron type boiler construction. The boiler operator should be able to describe the differences between package and site-erected boilers. The boiler operator should be able to describe the differences between package and site-erected boilers. The boiler operator must know the difference between a longitudinal weld joint and circumferential weld joint. The operator should be able to describe the flow of gases through each type of boiler.
b. Heat Transfer – The boiler operator must understand conduction, convection and radiation heat transfer. The boiler operator should be able to describe the various types of fluid flow and how they affect heat transfer. The density of steam versus boiler pressure, and the meaning of saturation temperature must be understood.
c. Steam, properties and Control Devices – The boiler operator should know location and purpose of a dry pipe, cyclone steam separators, steam scrubber, or baffles. The boiler operator should know the function, types, location, operation, start up, and efficiency of superheaters. Have an understanding of the affects of carryover and how it is prevented, steam quality, and desuperheaters or attemperators.
d. Furnace Design – The boiler operator should understand the reason(s) for having ash re-injection, furnace baffles, and water walls (water cooled furnace). The boiler operator should have knowledge of soot blower operation, types and location. Refractory walls, slag, erosion and spalling, purpose of a water screen, flame impingement, clinkers, clinker crinders are topics with which the boiler operator should be familiar.
e. Economic Devices – The boiler operator should know the construction location, types, and purpose of an economizer, air-preheaters, and thermocouples.
f. Firing Equipment – The boiler operator should understand and be able to operate pulverized firing, chain grate firing, spreader stoker firing, and underfeed stoker firing.
g. Draft – The boiler operator should understand balanced draft units, pressurized draft unit, primary air, secondary air, tertiary air.
Boilers – Construction; materials, support, types of stress, openings and fittings, heating surface and capacity.
3. Boilers Construction – The boiler operator must be aware of the materials, design, and limits of those materials used in the equipment in their charge. Stress the access for cleaning, inspection, and repairs, as well as the appliances attached to the boiler to ensure it does not exceed the limits of its design. In addition, the operator must know the abilities and limits of the unit being operated to prevent failures of equipment that may result in injury or death.
a. Materials – The boiler operator must have knowledge and understand limitations of materials used in boiler construction. The boiler operator should have knowledge of proper operating procedure, which will help to prevent creep or graphitization. Being able to specify the nondestructive examination method to be used to inspect the boiler is also part of the knowledge needed by the boiler operator.
b. Openings and Fittings – The boiler operator should know the requirement for the minimum size of a manhole or hand hole opening. In addition, he must able to list the purpose of other openings in the drum, and be able to identify the process of rolling tubes into a boiler.
c. Heating Surface and Capacity – The boiler operator should know the definition of heating surface, and how twelve square feet of heating surface is related to Ohio law concerning licensed operators and engineers. The operator must be able to convert evaporation rate to horsepower.
Combustion-fuels, control of the rate of combustion.
4. Combustion – The boiler operator must be proficient in the techniques used to control fuel and air to a furnace, thus regulating the release of heat to the boiler.
a. Fuels and their equipment – The boiler operator should know the combustion process, temperature required for combustion, atomization, and absolute pressure.
b. Control of the rate of Combustion – The boiler operator should know how to control the supply air (oxygen) part of combustion, the condition or degree under which combustion takes place, flue gas analysis methods, the amount of air required to burn a pound of fuel, and tempering of fuel.
Combustion Equipment-specific types of equipment for each type of fuel including safety devices, monitoring and adjusting fuel burning equipment, and mechanical and draft.
5. Combustion Equipment – The boiler operator must be familiar with the devices used to supply fuel to the furnace. This includes using solid, gaseous, or liquid fuels; the protective devices, types of controls used, and understand the type or types of draft required for each fuel including units that operate on multiple fuels.
a. Combustion Equipment – The boiler operator should know operation and maintenance of coal stokers, such as chain grate, spreader underfeed, and pulverize. Must know oil fired burners, mechanical or pressure type, and the advantages and disadvantages of each. In addition, operation and maintenance of gas-fired burners whether the supply is natural or man made. The operator must be able to describe the method of disposing of ash and products of combustion, and know the physical requirements of the fuel system.
b. Safety Devices – The boiler operator must be able to explain how to properly fire a boiler. The boiler operator must be able to explain the importance of purging the furnace and of heating or pressurizing the fuel. The operator must know what devices are to be installed in the fuel system to protect it.
c. Monitoring the furnace – The boiler operator must be able to explain what can happen if the burner flame is not controlled properly.
d. Draft – The boiler operator shall see to it that induced, over fire, and forced draft fans are operational, and must determine if a balanced draft on positive pressure furnace is distributing heat and gases as required to prevent failure in the furnace.
Boiler Indicators and Devices – to provide for operation, prevent over-pressure, determine water level, valves, piping blow down systems, and measuring devices.
6. Boiler Indicators and Devices – The boiler operator must have knowledge of operation and maintenance relating to the devices that are provided to assist in determining and maintaining water level, steam pressure, isolating the boiler, and preventing over pressure of the boiler. The devices shall be in the proper location, using recommended code installation practices.
a. Safety Devices – the boiler operator shall know the operation, maintenance, location, purpose, and proper installation of a boiler water column, safety valve, blow down valve, heater/non return valve, steam gauge, fusible plug, and feed water regulator.
b. Safety Valve – The boiler operator shall be able to properly test the safety valve of the boiler and know the minimum number of valves required for installation. The boiler operator must know the requirements for; discharge piping, minimum blowback values, and the minimum capacity for safety valves.
c. Boiler Water Level Devices – The boiler operator will know the proper procedure to determine the water level of the boiler, the location of the water column and the minimum size, strength, and type of pipe and fittings sued.
d. Valves and their applications – For each appliance, the boiler operator will know the type of valve used in which order is used on feed water, blow down, steam header, water column, and all other connections to the boiler.
e. Instrumentation – The boiler operator shall know how to use all measuring devices, insure that they are attached properly, and be able to perform test to prove their accuracy. These items may include; steam gauges, draft gages, water gauges, fuel, and temperature gauges.
Boiler Operation-abnormal operations, start up, shut down, efficiency, water supplies, idle boilers, maintenance, repairing, and evaluation of a boilers’ condition
7. Operation and Maintenance – The boiler operator must show evidence that indicates the comprehension of the theory of the production of steam from boilers, during all phases of operation, maintenance, repairs, and inspection.
a. Start Up and On-line Operation of Boilers – The boiler operator should understand the sequence of operation that lends up to on-line operation. This includes any special considerations for new or newly repaired boilers.
b. Combustion – The boiler operator should be able to monitor, analyze, and regulate the combustion process to operate in the most efficient and safe manner.
c. Operational Problems – The boiler operator needs to be able to recognize problem areas immediately and control potentially un-safe operation. Abnormal operation, priming and carry over, tube failure, fires, inconsistent draft, and gauge glass breakage are some of the situations that an operator must, at all times, be ready to handle.
d. Idle Boilers – The boiler operator should be able to care for idle boilers, know how to take a boiler out of service, and know how to place a boiler in wet or dry lay up.
e. Boiler maintenance – The boiler operator should be able to; perform routine maintenance, schedule maintenance, prepare boilers for internal inspections, and external inspections, or repairs. To obtain maximum efficiency in operation the boiler needs to be maintained on a regular schedule.
Pumps-type, applications, facts used in selecting, conditions for operating, and maintenance.
8. Pumps – The boiler operator shall demonstrate knowledge indicating comprehension of the operation, maintenance, start-up and shut down of all types of pumps used throughout a powerhouse.
a. Pumps- The boiler operator must be able to identify the types of pumps and the varied uses of pumps. The operator must understand their capabilities and what can be expected of injectors, duplex pumps, power pumps, vacuum pumps, rotary pumps, and centrifugal pumps.
b. Pump Operation – The boiler operator needs to be able to properly line up and bring pumps on line, regulate pump discharge and understand the performance characteristics of the pump.
c. Pump Maintenance – The boiler operator needs to know when and how to care for each type of pump, must identify the required routine maintenance, and schedule maintenance, to maintain peak performance of all types of pumps.
Boiler Auxiliary Support Equipment – types and operations of feed water heaters, water system make up, condensate, polished systems, blow down systems, steam traps, separators, lubricator types and devices with their auxiliaries
9. Boiler Auxiliary Support Equipment – The boiler operator shall demonstrate knowledge that indicates comprehension of the operation, maintenance, start-up and shut down of boiler auxiliary equipment used through out a powerhouse. These items include pre-heating, water treatment, distribution of steam, return of condensate, and lubrication operations.
a. Feedwater Heating Equipment – The boiler operator needs to know feed water heaters, closed and open, and deaerators. The boiler operator must have a thorough understanding of preheating of feedwater, and which components provide these benefits.
b. Boiler Water Treatment – The boiler operator needs to know water treatment. To maintain peak performance and limit down time, water quality is of great importance to safe operation. The boiler operator must be able to analyze and chemically treat water for each condition. The boiler operator must understand the affects of blowing down a boiler.
c. Piping Systems for Steam and Condensate – The boiler operator needs to know piping systems design, material selection, flanges and fittings are topics with which the operator must be familiar.
d. Steam Traps – The boiler operator needs to know the various designs and types of steam traps, separators, and strainers. To gain the most efficiency from the steam, it is dried for use using separators.
e. Lubrication – The boiler operator must understand classification and uses of lubricants and lubricating devices. The applicant must know what provides the best protection and reduces friction, and the different methods of application.
Environment Control –types, technology, particulate control, equipment for specific controls, mechanical, bag filter, and precipator.
10. Environmental Control – The boiler operator shall demonstrate knowledge that indicates comprehension of the operation, maintenance, start-up and shut down of environmental equipment and to comply with environmental responsibilities of the plants operation.
a. Pollution Controls and Standards – The boiler operator needs to know the types of emissions, how they are monitored, and the operator must be able to differentiate one condition from another, and control the situation accordingly.
b. Pollution Control Devices – The boiler operator needs to know how particulates are controlled, mechanical collectors, electrostatic precipitators, bag filter houses, how to control pollution by-products or stack gas emissions are topics with which the operator must be familiar. The applicant needs to identify the different methods available and the principles of operation.
c. Flue Gas Scrubbers – The boiler operators needs to know how to operat sulfur dioxide scrubber, wet scrubber, and dry scrubber. In addition to particulate control, the chemical balance as a result of combustion needs to be reduced to acceptable atmospheric standards.
Math formulas
11. Math Formulas – Math from the text the boiler operator must know the formulas, as there will be no books, notes, and no programmable calculators allowed under NIULPE Engineered test.
a. The internal design pressure of an existing boiler.
b. Absolute pressure.
c. Rate at which tons of coal are being consumed in a chain grate stoker.
d. Pressure due to head of water.
e. Tons of coal to develop pounds of steam per hour.
f. Collection efficiency of an electrostatic precipitator.
g. Pounds of water to condense one pound of steam.
Laws and Rules
12. Laws and rules pertaining to the licensing of Stationary Boiler Operators, Boiler Operators and Low Pressure Boiler Operators
a. Horsepower by heating surface
b. Licenses renewals
c. License revocation and expiration
d. Experience and schooling
e. Display of license
f. Requirements of boilers over thirty (30) horsepower by heating surface.
Boiler Tech 2 Book:
- 1: Stationary Engineering Principles
- 2: Boilers
- 3: Steam and Water Fittings
- 4: Fuels and Combustion
- 5: Boiler Operation and Maintenance
- 6: Steam Turbines
- 7: Steam Turbine Operation and Maintenance
- 8: Water Treatment
- 9: Electrical Principles
- 10: Steam Management
- 11: Computer-Integrated Control Systems
- 12, 13, 14: Licensing Exams
- 15: Reciprocating Steam Engines
This new edition of Stationary Engineering covers all aspects of boiler operation and auxiliary equipment. A new section on condensing boilers combined with new information on soot blowers and superheater design provides coverage for licensing examination preparation, in industrial classes, or as a reference for studying boiler principles and for upgrading skills. The Index has been thoroughly updated to make it easier to find relevant information.
1: The fuels of Combustion
2: Combustion
3: Time – Temperature – Turbulence
4: Combustion Testing
5: Testing, Adjustment and Verification
6: Draft
7: Stack Temperature and Efficiency
8: Carbon Monoxide Safety
